Setting WA_NativeWindow on QQuickWidget doesn't render anymore, all black

    XMLWordPrintable

Details

    • Bug
    • Resolution: Unresolved
    • P1: Critical
    • None
    • 6.8.3
    • Qt RHI
    • None
    • Windows

    Description

      We wanted to embed a QQuickWidget in a docking container within our QMainWindow, without running through the render surface type conversion of the mainwindow's default raster surface to direct3d/opengl surface. According to the recent fixes done for QTBUG-119221 , this should be now doable by setting the Qt::WA_NativeWindow on the quickwidget.
      See comment from vestbo in QTBUG-119221 and related defect:

      Set Qt::WA_NativeWindow on the QOpenGLWidget/QRhiWidget/QQuickWidget/QWebEngineView, or one of its parent widgets, to composit only that widget's hiearchy using RHI. The parent widget hierarchy should not be affected (WA_DontCreateNativeAncestors and AA_DontCreateNativeWidgetSiblings still apply as normal).

      541664 adds support for separate RHI flushing per native window.

      But when setting the Qt::WA_NativeWindow flag the quickwidget doesn't render anymore and window content is black.

      This is a simplified repro sample with a quickwidget in a dialog, instead of a dockwidget, but the same occurs when you try to put the quickwidget in a dockwidget:

      #include <QtWidgets/QApplication>
      #include <QtWidgets/QtWidgets>
      #include <qquickwidget.h>

      class QuickWidgetDialog : public QDialog
      {
      public:
      	QuickWidgetDialog(QWidget* parent = nullptr)
      		: QDialog(parent, Qt::Dialog)
      	{
      		setWindowTitle("QuickWidget Dialog Host");
      		setAttribute(Qt::WA_DeleteOnClose, true);

      		auto horzLayout = new QHBoxLayout(this);
      		auto quickWidget = new QQuickWidget();
      		quickWidget->setAttribute(Qt::WA_NativeWindow);
      		quickWidget->setSource(QUrl::fromLocalFile("Panel.qml"));
      		horzLayout->addWidget(quickWidget);
      	}
      };

      int main(int argc, char** argv)
      {
      	QApplication app(argc, argv);

      	auto dlg = new QuickWidgetDialog();
      	dlg->resize(640, 480);
      	dlg->show();

      	return app.exec();
      }


      Note, that with the recent changes in QWidget::setParent() releated to RHI & setting up the backing store, everything strongly depends on whether at parenting time the parent's windowHandle() is already created or not, see closestParentWidgetWithWindowHandle().
