Text of explicitly declared Buttons in DialogButtonBox not rendering

    XMLWordPrintable

    Details

    • Commits:
      b10912ba731144e8c41cbfa35fb1553ad04b2b88 (qt/qtquickcontrols2/5.14)

      Description

      When running https://github.com/mitchcurtis/slate with Qt 5.13.1, I can see the text of buttons in a DialogButtonBox. With 5.13.2 and later, it's gone.

      Steps to reproduce:

      1. Run the app
      2. Ctrl+N
      3. Click "New Image"
      4. Text of buttons in bottom-right of dialog is missing

      I haven't been able to isolate this in a minimal example yet. I don't think it's the same as QTBUG-76229, as the workarounds for that and the qtdeclarative patch don't help.

      Here's a link to binaries:

      https://drive.google.com/open?id=18fIthXkzBT70jWanI_YqGzAY7qBs-ghh

      System info from Creator:

      Screens: 1, High DPI scaling: inactive
      # 0 "Colour LCD" Depth: 24 Primary: yes
        Manufacturer:
        Model:
        Serial number:
        Geometry: 1680x1050+0+0 Available: 1680x1027+0+23
        Physical size: 330.791x206.744 mm  Refresh: 60 Hz Power state: 0
        Physical DPI: 129,129 Logical DPI: 72,72 Subpixel_RGB
        DevicePixelRatio: 2 Pixel density: 1
        Primary orientation: 2 Orientation: 2 Native orientation: 0 OrientationUpdateMask: 0

      LibGL Vendor: ATI Technologies Inc.
      Renderer: AMD Radeon Pro 460 OpenGL Engine
      Version: 2.1 ATI-2.11.21
      Shading language: 1.20
      Format: Version: 2.1 Profile: 0 Swap behavior: 2 Buffer size (RGB): 8,8,8
      Profile: None (QOpenGLFunctions_-867631232_32722)


      I had someone test it on their MacBook Pro with 10.14.2 and it worked for them (with 5.13.2), so it might be a problem with hardware or the OS version.

      I also managed to reproduce it on Ubuntu 16.04 in a VM.
