doxygen dedicated output parser

    XMLWordPrintable

Details

    • Bug
    • Resolution: Won't Do
    • Not Evaluated
    • None
    • Qt Creator 5.0.3
    • Project & Build Management
    • None
    • Linux/X11

    Description

      Hello,

      when running a CMake project in QtCreator that calls doxygen, the output warnings printed to the terminal by doxygen are correctly identified in the "Issues pane" of QtCreator.
      However, the Issue Pane is missing some lines when the output is multi-line:

      For example, the output is:

      /opt/root_src/io/io/src/TGenCollectionProxy.cxx:640: warning: no matching class member found for
  TGenCollectionProxy::TGenCollectionProxy(const ROOT::TCollectionProxyInfo &info, TClass *cl)
Possible candidates:
  'TGenCollectionProxy::TGenCollectionProxy()'
  'TGenCollectionProxy::TGenCollectionProxy(const TGenCollectionProxy &copy)'
  'TGenCollectionProxy::TGenCollectionProxy(Info_t typ, size_t iter_size)'
  'TGenCollectionProxy::TGenCollectionProxy(const ROOT::Detail::TCollectionProxyInfo &info, TClass *cl)'

      The Issues Pane only shows the first message, double clicking on it does not unfold the possible candidates / solutions. It would be nice to have a dedicated output parser for doxygen within QtCreator.

      Attachments

        1. image-2022-01-19-12-31-13-120.png
          21 kB
          Ferdy Mercury
        2. screenshot-1.png
          220 kB
          Ferdy Mercury
        3. screenshot-2.png
          41 kB
          Ferdy Mercury
        4. testdoxy.zip
          36 kB
          Ferdy Mercury
        5. image-2022-02-24-14-11-30-538.png
          34 kB
          Ferdy Mercury
        6. image-2022-02-24-14-16-25-404.png
          46 kB
          Ferdy Mercury
        7. image-2022-02-24-14-30-15-845.png
          101 kB
          Ferdy Mercury
        8. image-2022-02-24-15-39-47-990.png
          24 kB
          Ferdy Mercury
        For Gerrit Dashboard: QTCREATORBUG-26892
        # Subject Branch Project Status CR V
        397845,2 ProjectExplorer: Respect leading whitespace in custom output parsers 7.0 qt-creator/qt-creator Status: MERGED +2 0
